Description
Main features:
1. Suitable for aerobic fermentation, can be used with solar fermentation room, fermentation tank and transfer machine, etc. Used with transfer machine, it can realize the function of one machine with multiple tanks.
2. The fermentation tank matched with it can discharge materials continuously or in batches. Efficiency, smooth operation, sturdy and durable, even flipping.
3. Centralized control of the control cabinet can realize manual or automatic control functions, and is equipped with a soft starter, with low impact load at startup. A wireless remote control device can also be installed.
4. Optional palladium tooth lifting system (lifting system is divided into three types: hydraulic, electric and pneumatic). The lifting system is mainly suitable for one-way flipping process, and the return can return empty. It is also conducive to restarting in the middle of the journey and debris stuck.
5. The palladium tooth is made of manganese steel and is quenched and durable. It has a certain ability to crush and mix materials and is easy to replace.
6. The limit travel switches are equipped at both ends of the guide rail, which play a role in limit and safety, and can also realize the automatic control of automatic return at the arrival end.
Advantages:
simple operation, short fermentation cycle, full fermentation, low pollution, easy expansion, and certain crushing and mixing functions for materials
Usage:
fermentation of poultry and livestock manure, sludge garbage, straw sawdust, dregs, cakes, sugar factory filter mud, etc.
Suitable groups:
organic fertilizer plants, compound fertilizer plants, gardening fields, sludge garbage plants, Agaricus bisporus cultivation fields, etc.
Product attributes:
model | power | dimensions | Speed of work | No-load speed | Compost turning width | Turning depth |
---|---|---|---|---|---|---|
HQ-FD3m | 18.5 | 3400*2120*1952 | 50 | 100 | 3000 | 1000 |
HQ-FD4m | 22 | 4400*2120*1980 | 50 | 100 | 4000 | 1200 |
HQ-FD5m | 22×2 | 5400*2120*1980 | 50 | 100 | 5000 | 1500 |
HQ-FD6m | 30×2 | 6400*2120*1980 | 50 | 100 | 6000 | 1500 |
