Description
Advantages:
Designed and manufactured using a new wet continuous push rod granulation process. Not only can it granulate a variety of organic matter, especially for crude fiber materials that are difficult to granulate using conventional equipment, such as crop straw, wine dregs, fungus dregs, drug dregs, animal feces, etc., which can be granulated after fermentation, but also the granulation effect of raw materials such as humic acid and urban sludge is also very good. It is used to granulate various organic matter after fermentation, breaking through the conventional organic matter granulation process. Before granulation, there is no need to dry and crush the raw materials. Spherical particles can be processed directly by mixing the ingredients.
Equipment features: The particles produced are spherical. The organic content is high, and pure organic granulation is achieved. The stirring tooth granulation production equipment uses the characteristics of organic particles that can grow together under a specific force. The stirring tooth granulation production equipment does not need to add a binder when granulating. The particles are solid and can be screened after granulation to reduce drying energy consumption. The organic matter does not need to be dried after fermentation, and the moisture content of the raw materials can be 20-40.
Usage:
Granulation of feces, sludge, clinker and fertilizer
Suitable for:
organic fertilizer, inorganic fertilizer, compound fertilizer, composite fertilizer, biological fertilizer, blended fertilizer, formula fertilizer, BB fertilizer factory, winery, mushroom breeding factory
product properties:
model | power | Dimensions | Yield | |
1200*6000 | 18.5+7.5 | 7500*2000*2000 | 2-5t/h | The frame adopts channel steel structure and the drum is submerged arc welded; |
1500*6000 | 18.5+11 | 8100*2360*2300 | 4-7t/h | 2. The internal stirring teeth are made of 45# steel with multiple deep processing; 3. Alloy cutter head; |
1800*6000 | 22+15 | 8200*2650*2750 | 6-10t/h | 4. The granulating drum belt, gear ring, tug and bracket are made of ZG310-570 |
