Description
Advantages:
It has uniform granulation force and high yield rate. It is an organic-inorganic compound fertilizer, organic fertilizer, and biological organic fertilizer granulation equipment. Due to the coarse fiber characteristics of the material, the balling rate of the stock granulator is low, and the stirring tooth granulator cannot make materials with high ball content (easy to stick to the wall). This granulator overcomes the shortcomings of both-it can produce organic fertilizer, organic fertilizer stirring tooth granulator and stock granulator. It is suitable for coarse fiber materials that are difficult to granulate with conventional equipment. The outer shell is welded with thickened high-carbon steel plates, and the supporting equipment includes tugboat parts, tugboats, transmission parts, wind heads, wind tails, etc. The stable base design makes it run more smoothly. The granulator is a kind of equipment that processes powdered fertilizer into granules. It is suitable for high-nitrogen products such as organic-inorganic compound fertilizers. It is widely used in organic wastes such as peat, sludge, chicken manure, livestock manure, lignite, distiller’s grains, bean dregs, and sugar factory filter mud. The granulator uses the characteristic that organic particles can embed and grow together under a specific force. No binder needs to be added during granulation, and the particles produced are spherical.
Usage and purpose:
This granulator adopts three-combination type, combined with organic fertilizer stirring tooth granulator and rotary granulator, it can granulate a variety of organic matter. For crude fiber materials that are difficult to granulate using conventional equipment, such as crop straw, wine residue, fungus residue, medicine residue, animal feces, etc., they can be granulated after fermentation, and it has good granulation effect on raw materials such as humic acid and urban sludge.
Suitable for:
peat, sludge, chicken manure, livestock manure, lignite, wine lees, bean dregs, sugar factory filter mud, cat litter particles and other organic wastes.
product properties:
model | size | power | Outer tube thickness | Frame material | Segment Material | Segment bolt assembly | Reducer model | Production Capacity |
1200*6000 | 7500*2000*2000 | 18.5+7.5 kw | 10mm | Channel steel structure | Alloy blade | 10.8 grade high strength bolts | ZD reducer | 2-5t/h |
1500*6000 | 8100*2360*2300 | 18.5+11 kw | 12mm | Channel steel structure | Alloy blade | 10.8 grade high strength bolts | ZD reducer | 4-7t/h |
1800*6000 | 8200*2650*2750 | 22+15 kw | 14mm | Channel steel structure | Alloy blade | 10.8 grade high strength bolts | ZD reducer | 6-10t/h |
